Arlows beaded weld-on end stainless steel V2A
Corrosion resistant. Slip-proof. Up to 4 bar. Precision machined end with bead for tight and durable charge air connections.
Made from stainless steel 1.4201 (precision machined). The pronounced bead locks the silicone hose and clamp in place, even under high boost. 30 mm length. Weld to the tube, then fit hose and clamp. Diameter is selected in the variant. Laser etched Arlows logo.
Why this end piece?
BEAD
Integrated bead as stop. The hose does not creep under the clamp. Tested up to 4 bar boost, no leaks.
STAINLESS
Stainless steel 1.4201. Extremely corrosion resistant and durable. Ideal for moist or aggressive environments.
30 MM LENGTH
Compact and stable. Ideal for tight installations. Precision machined for a clean fit.
WELD ON
Perfect for welding to stainless steel tubes. Clean, porosity-free welds. Robust and lasting.
Use cases
- Charge air piping (charge pipe to silicone hose)
- Intake tubes and cold air routing
- Custom hard lines where the hose needs a secure hold
- Environments with moisture or higher corrosion load
Technical data
| Material | Stainless steel 1.4201 (precision machined) |
| Length | 30 mm |
| Design | beaded weld-on end |
| Pressure | tested up to 4 bar |
| Diameter | see variant selection |
| Processing | weld, deburr |
Fitment
Match the diameter to the tube and hose. Deburr the ends. Weld to the stainless steel tube. Then slide on the silicone hose and tighten with a clamp. The bead prevents slipping under pressure and vibration.
| Manufacturer: | Arlows |
| Category: | ALUMINUM PIPES |
| Item number: | AR12387-19 |
| Product weight: | 0,10 Kg |
